Eletrical Specification
resolution	4 mil
Input voltage	DC 5V ± 0.25 V
Power	250 mW ( work ) : 500 mW ( maximum instantaneous )
Current	50 mA ( work ) : 100 mA ( maximum instantaneous )
Optical specifications
Source Type	Visible laser diode
Wavelength	650nm
Decode rate	120 scan/sec
Scan angle	± 60 ° ± 65 ° ± 42 ° ( right and left , front and rear , turn )
BER	1/ 50000000
Light Intensity	3000-12000Lux
King Deep	5mm-630mm
Decode Capability	UPC / EAN / JAN, UPC / EAN with Supplementals, UCC / EAN 128, Code 39, MSI, Code11, Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128Full ASCII, Codabar, Code93, Discrete2of5, IATA, RSSvariants, Codabar, Chinese2of5, Inteleaved2 / 5, Interleaved2of5, the postal code and other international general - dimensional bar code-Lift method: Buzzer , LED indicator .
Physical Specification
Cable Interface	種功能-手動，自動觸發，自動感應器
Cable length	鍵盤楔：XT / AT和PS2，RS232，USB接口

Dimensions	63(L)x87(W)x165(D)mm
Weight	ABS, PS, PC
Interface Type	145g (EXCL cable)
Shell Material	2m
Temperature	迷你 DIN6
Setting	DB9 (MALE)
