| Physical Parameters |
| Dimension (L x W x H) |
105 mm x 146 mm x 70 mm |
|
Weightt |
418g |
| Voltage |
5VDC |
| Current |
500mA (Operating) |
Performance Characteristics |
| Light Source |
Illumination: 5600K LED |
| Field of View |
40° (H) x 25° (V) |
| Pitch/Yaw |
360°, ±65°, ±60° |
| Print Contrast |
20% minimum reflective difference |
| Symbology Decode Capability |
| 1D |
UPC, EAN, Code 128, Code 39, Code 93, Code 11,
Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey,
GS1 DataBar, China Postal, Korean Postal, etc. |
| 2D |
PDF417, MicroPDF417, Data Matrix, Maxicode, QR Code,
MicroQR, Aztec, Hanxin, etc. |
| Minimum Resolution |
5 mil Code 39 |
| Interfaces Supported |
USB, RS232 |
| User Environment |
| Operating Temperature |
32° to 122° F / 0° to 50° C |
| Storage Temperature |
-40° to 158° F / -40° to 70° C |
| Humidity |
5% to 95%, non-condensing |
| Drop/Shock Temperature |
Withstands 10Gs 0.06” double amp |
| Ambient light Immunity |
Immune to indoor lighting up to 1600 Lux.
Immnune to sunlight up to 86,000 Lux. |
| User Environment |
| 5 mil (Code 39) |
0mm-40mm |
| 13 mil (100% Upca) |
0mm-200mm |
| Performance may be impacted by bar code quality and environment conditions |
