| General |
|
| Resolution |
|
| Printing Method |
| |
Thermal Transfer/Direct Thermal |
|
| Max.print speed(Max.) |
|
| Max.print width(Max.) |
|
| Max.print length(Max.) |
|
| Media Type |
| |
Continuous, gap, black mark, fan-fold and punched hole |
|
| Media Width |
|
| Media Thickness |
| |
0.06~0.254mm (2.36~10mil) |
|
| Label Length |
|
| Label Roll Capacity |
| |
127mm (5") external diameter |
|
| Ribbon & Ribbon Width |
| |
300m, Max roll diameter 67mm, Core Diameter:1", 40mm-110mm (1"-4.3") |
|
| Enclosure |
|
| Dimension |
| |
299mm (D) x 230mm (W) x 196mm (H) |
|
| Weight |
|
| Processor |
|
| Memory |
| |
4MB Flash Memory
8MB SDRAM
Micro SD card reader for Flash memory expansion, up to 4GB |
|
| Interface |
| |
USB 2.0(standard)/TFD Card(Standard)/Serial(Optional)/Parallel(Optional)/LAN(Optional)/ WIFI(Optional)/Bluetooth(Optional) |
|
| Power Supply |
| |
Built-in power supply with auto switching
Input: AC 100-240V, 1.8A, 50-60Hz
Output: DC 24V, 2.5A, 650W |
|
| Operations witch, button, LED |
| |
1 power switch, 1 feed button, 1 LED (3 colors: red, purple, blue) |
|
| Sensor Type |
| |
Transmissive gap sensor (position adjustable)
Black mark reflective sensor (position adjustable)
Ribbon end sensor
Print head open sensor |
|
| Real Time Clock |
|
Internal Fonts |
| |
8 alpha-numeric bitmap fonts
Windows fonts are downloadable from software |
|
| Barcodes |
| |
1D bar code: Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8, EAN-13
EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11
2D barcode: PDF-417, Maxicode, DataMatrix, QR Code |
|
| Graphics |
| |
BIMAP, BMP, PCX(Max.256 colors) |
|
| Font and Barcode Rotation |
|
| Printer Language |
|
| Environment Condition |
| |
Operation Temperature: 5°C-40°C (41°F-104°F), Humidity (non-condensing): 25-85%
Storage: -40°C-60°C(-40°F-140°F), Humidity (non-condensing) 10%-90% |
|
| Safety Regulation |
|
